John Deere X540
| | 2006 - 2014 |
|
| Select X500 Series | | Garden tractor |
|
Series map:
X534
X540
25.0hp
26.0hp
| Production |
| Manufacturer | John Deere
|
| Garden tractor |
| Built in Horicon, Wisconsin, USA |
| Mechanical |
| Two-wheel drive |
| Differential lock | mechanical rear
|
| Steering | power
|
| Open operator station with 16-inch seat and 7-inch adjustment. Cupholder, toolbox, and 12-volt outlet standard. Tilt steering wheel. |
| Tractor hitch |
| Type | sleeve hitch OptOptional
|
| Power Take-off (PTO) |
| Mid PTO | independent
|
| Clutch | electric
|
| X540 Serial Number Location |
 |
| Serial number tag on the front-right of the X540 tractor frame, above the front axle. |
| Electrical |
| Ground | negative
|
| Charging amps | 15
|
| Battery CCA | 500
|
| Battery volts | 12
|
| References |
 |
| Select Series Tractors published in 2007, by John Deere |
| Select Series Tractors published in 2009, by John Deere |
| Commercial & Consumer Equipment Purchasing Guide published in 2007, by John Deere |
| Riding Lawn Equipment Attachments & Accessories published in 2011, by John Deere |
 |
| Operator's Manual X500 Series Tractors (OMM153412) published in 2005 |
| Operator's Manual X500 Series Tractors (OMM155821) published in 2006 |
| Operator's Manual X500 Series Tractors (OMM157372) published in 2008 |
