| | 2002 - 2005 |
| HDGT X Series | | Garden tractor |
|
Series map:
X475
X485
X495
23.0hp
25.0hp
24.0hp
| Transmission |
| Transmission | Tuff Torq K92
|
| Type | shaft-driven hydrostatic
|
| Gears | infinite forward and reverse
|
| 2WS Oil capacity | 7 qts
6.6 L
|
| AWS Oil capacity | 6 qts
5.7 L
|
| Oil type |
|
| Hydrostatic transmission operator with dual foot pedals. Cruise control on dashboard. |
| Speeds |
|
| X485 Transmission Controls |
 |
| 1 | Throttle
|
| 2 | Brake
|
| 3 | Forward
|
| 4 | Reverse
|
| 5 | Parking brake
|
| 6 | Cruise control
|
| 7 | Differential lock
|
