Lawn Tractors > John Deere > X465

John Deere X465



John Deere X465 tractor photo
2002 - 2005
HDGT X Series
Garden tractor
Series map:
X465
X475
21.0hp
23.0hp
Production
ManufacturerJohn Deere
Garden tractor
Built in Horicon, Wisconsin, USA
Original price$7,470 (2004 2WD )
$7,870 (2004 AWS )
Variants
X465AWSall-wheel steer
John Deere X465 Engine
21HP Kawasaki 686cc 2-cyl gasoline
Fuel tank6.5 gal
24.6 L
Engine details ...
John Deere X465 Transmission
hydrostatic
Transmission details ...
Mechanical
Two-wheel drive
Differential lockmechanical rear
Steeringhydrostatic power
 four-wheel steering on X465 AWS
Integral wet disc brakes
Open operator station. Optional hard and soft-sided cabs. Optional vinyl weather enclosure.
Photos
No photos of the John Deere X465 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type0 OptOptional
 1-limited OptOptional
Rear lift450 lbs
204 kg
Power Take-off (PTO)
Rear PTOindependent OptOptional
Rear PTO Type540
Mid PTOindependent
Clutchelectric
Dimensions & Tires
Wheelbase54.5 inches
138 cm
Weight830 to 885 pounds
Front tire18x8.5-8
Rear tire26x12-12
Full dimensions and tires ...
John Deere X465 attachments
48" mid-mount mower deck
54" mid-mount mower deck
62" mid-mount mower deck
snowblower
blade
Attachment details ...
X465 Serial Number Location
John Deere X465 serial number location
Serial number decal on the middle-right of the main tractor frame.
X465 Serial Numbers
2002010001
2003020001
2004030001

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps20
Battery CCA340
Battery volts12
References
X465 references literature
Lawn and Garden Product Information Handbook published in 2002, by John Deere
Lawn and Garden Product Information Handbook published in 2003, by John Deere
Lawn and Garden Product Information Handbook published in 2004, by John Deere
Premium Lawn and Garden Tractors published in 2004, by John Deere
Lawn and Garden Tractors published in 2000, by John Deere
Lawn and Garden Tractor X465, X475, X485 Operator's Manual (OMM148634) published in 2002
Lawn and Garden Tractor X465, X475, X485 Operator's Manual (OMM150215) published in 2004
