| | 1968 - 1974 |
| 100 Series | | Garden tractor |
|
Series map:
120
140
12.0hp
12.0hp
| Transmission |
| Transmission | Sundstrand 15
|
| Type | shaft-driven hydrostatic
|
| Gears | infinite forward and reverse
|
| Oil capacity | 5 qts
4.7 L
|
| Oil type |
|
| Oil change | 500 h
|
| Speeds |
|
| 140 Transmission Controls |
 |
| 1 | Clutch
|
| 2 | Forward/Reverse
|
| 3 | Throttle
|
| 4 | Brakes (not shown)
|
| 5 | Parking brake
|
