J.I. Case 310E Loader Engine
|
|
| Engine options | |
| J.I. Case 3.1L 4-cyl diesel | |
| J.I. Case 2.4L 4-cyl gasoline |
| Engine Detail | |
| J.I. Case G-188D | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 188.4 ci 3.1 L |
| Bore/Stroke | 3.8125x4.125 inches 97 x 105 mm |
| Power | 40 hp 29.8 kW |
| Air cleaner | oil bath |
| Compression | 17.5:1 |
| Rated RPM | 1850 |
| Torque | 128 lb-ft 173.6 Nm |
| Torque RPM | 1350 |
| Starter | electric |
| Starter volts | 12 |
| Coolant capacity | 13 qts 12.3 L |
| J.I. Case 310E Loader Engine | |
 |
| Engine Detail | |
| J.I. Case G-148B | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 148 ci 2.4 L |
| Bore/Stroke | 3.375x4.125 inches 86 x 105 mm |
| Power | 42 hp 31.3 kW |
| Fuel system | updraft carburetor |
| Air cleaner | oil bath |
| Compression | 7.25:1 |
| Rated RPM | 1850 |
| Torque | 128 lb-ft 173.6 Nm |
| Torque RPM | 1200 |
| Starter | electric |
| Starter volts | 12 |
| Coolant capacity | 12 qts 11.4 L |
| J.I. Case 310E Loader Engine | |
 |
