J.I. Case 480 CK Construction King


J.I. Case 480 CK Construction King tractor photo
1968 - 1971
Industrial tractor
Production
ManufacturerJ.I. Case
Industrial tractor
J.I. Case 480 CK Engines
J.I. Case 3.1L 4-cyl diesel
J.I. Case 2.4L 4-cyl gasoline
Engine details ...
J.I. Case 480 CK Transmissions
4-speed mechanical shuttle
8-speed mechanical shuttle
Transmission details ...
J.I. Case 480 CK Power
Engine (gross)41.5 hp
30.9 kW
Engine (net)37 hp
27.6 kW
Mechanical
Two-wheel drive
Final drivesspur gear
Differential lockmechanical rear OptOptional
Power steering
Open operator station.
Photos
No photos of the J.I. Case 480 CK are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel22 gal
83.3 L
Hydraulic system5.5 gal (loader)
20.8 L
 11 gal (backhoe)
41.6 L
Hydraulics
Typeopen center
Capacity5.5 gal (loader)
20.8 L
 11 gal (backhoe)
41.6 L
Pressure1750 psi (loader)
120.7 bar
 2000 psi (backhoe)
137.9 bar
Pump flow13.5 gpm (loader)
51.1 lpm
 17.5 gpm (backhoe)
66.2 lpm
Dimensions & Tires
Gasoline Wheelbase77.2 inches
196 cm
Diesel Wheelbase78.4 inches
199 cm
Weight5630 to 8385 pounds
Front tire7.50x16
Rear tire13.6x24
Full dimensions and tires ...
References
480 CK Construction King references literature
Construction King 480/580/680 published in 1968, by J.I. Case
480 Construction King Loader published in 1968, by J.I. Case
