Caterpillar D5M



No photo available
1996 - 2002
Bulldozer
Series map:
D5M
121.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D5M Engine
Caterpillar 6.6L 6-cyl diesel
Engine details ...
Caterpillar D5M Transmission
3-speed power shift
Transmission details ...
Caterpillar D5M Power
Engine (gross)121 hp
90.2 kW
Engine (net)110 hp
82.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Two-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D5M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel57.6 gal
218.0 L
Hydraulic system17.7 gal
67.0 L
Hydraulics
Typeload sensing
Capacity17.7 gal
67.0 L
Pressure3000 psi
206.8 bar
Pump flow25 gpm
94.6 lpm
Dimensions & Tracks
Weight25800 lbs
11702 kg
22-inch tracks
Full dimensions and tracks ...
Caterpillar D5M attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps70
Batteries2
Battery CCA750
Battery volts12
Battery AH100
References
D5M references literature
D5M Track-Type Tractor published in 1996, by Caterpillar
D5M Track-Type Tractor published in 1998, by Caterpillar
