Caterpillar D5H
|
|
| Production | |
| Manufacturer | Caterpillar |
| Bulldozer | |
| Caterpillar D5H Engine | |
| Caterpillar 7.0L 4-cyl diesel | |
 Engine details ... |
| Caterpillar D5H Transmissions | |
| 6-speed direct drive | |
| 3-speed power shift | |
 Transmission details ... |
| Caterpillar D5H Power | |
| Engine (gross) | 129 hp 96.2 kW |
| Engine (net) | 120 hp 89.5 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | single-reduction planetary |
| Two-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Caterpillar D5H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 65 gal 246.0 L |
| Hydraulic system | 18.5 gal 70.0 L |
| Hydraulics | |
| Type | load sensing |
| Capacity | 18.5 gal 70.0 L |
| Pressure | 3000 psi 206.8 bar |
| Pump flow | 28.7 gpm 108.6 lpm |
| Dimensions & Tracks | |
| Weight | 21890 to 27530 pounds |
| 20-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| D5H Track-type Tractor published in 1986, by Caterpillar | |
| D5H Track-Type Tractor published in 1989, by Caterpillar |
