Tractors > Caterpillar > D4H Series II

Caterpillar D4H Series II



No photo available
1985 - 1996
Model year
Bulldozer
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D4H Engine
Caterpillar 5.2L 4-cyl diesel
Engine details ...
Caterpillar D4H Transmissions
6-speed gear
3-speed power shift
Transmission details ...
Caterpillar D4H Power
Engine (gross)99 hp
73.8 kW
Engine (net)95 hp
70.8 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Photos
No photos of the Caterpillar D4H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel44 gal
166.5 L
Hydraulic system7.8 gal
29.5 L
Hydraulics
Typeload sensing
Capacity7.8 gal
29.5 L
Pressure2700 psi
186.2 bar
Pump flow25.5 gpm
96.5 lpm
Dimensions & Tracks
Weight18452 to 22895 pounds
18-inch tracks
Full dimensions and tracks ...
Caterpillar D4H attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps35
References
D4H Series II references literature
D4H Series II Track-Type Tractor published in 1989, by Caterpillar
D4H Series II, D4H XL & LGP Series III published in 1992, by Caterpillar
