Caterpillar D4C
|
|
| Production | |
| Manufacturer | Caterpillar |
| Industrial Crawler tractor | |
| Caterpillar D4C Engine | |
| Caterpillar 5.2L 4-cyl diesel | |
 Engine details ... |
| Caterpillar D4C Transmission | |
| 3-speed power shift | |
 Transmission details ... |
| Caterpillar D4C Power | |
| Engine (gross) | 84 hp 62.6 kW |
| Engine (net) | 78 hp 58.2 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | spur gear |
| Four-post ROPS. Cab available with air-conditioning. | |
| Photos | |
| No photos of the Caterpillar D4C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 30.6 gal 115.8 L |
| Hydraulic system | 15 gal 56.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 15 gal 56.8 L |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 14.5 gpm 54.9 lpm |
| Dimensions & Tracks | |
| Weight | 13040 to 17360 pounds |
| 16-inch tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 40 |
| Battery volts | 12 |
| References | |
 | |
| D4C Track-Type Tractor published in 1988, by Caterpillar |
