Tractors > Caterpillar > D5K

Caterpillar D5K



Caterpillar D5K tractor photo
2007 - 2012
Bulldozer
Series map:
D5K
100.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D5K Engine
Caterpillar 4.4L 4-cyl diesel
Engine details ...
Caterpillar D5K Transmission
hydrostatic
Transmission details ...
Caterpillar D5K Power
Engine (gross)100 hp
74.6 kW
Engine (net)96 hp
71.6 kW
Mechanical
Drivecrawler
Final drivesdouble-reduction planetary
Cab standard with air-conditioning.
Photos
No photos of the Caterpillar D5K are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel51.5 gal
194.9 L
Hydraulic system15.7 gal
59.4 L
Hydraulics
Capacity15.7 gal
59.4 L
Pressure2988 psi
206.0 bar
Pump flow19.4 gpm
73.4 lpm
Dimensions & Tracks
Weight20741 lbs
9408 kg
20-inch tracks
Full dimensions and tracks ...
Caterpillar D5K attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps120
Batteries2
Battery CCA900
Battery volts12
References
D5K references literature
D5K Track-Type Tractor published in 2007, by Caterpillar
