Tractors > Caterpillar > D5C Series III

Caterpillar D5C Series III



Caterpillar D5C Series III tractor photo
1991 - 2001
Model year
Bulldozer
Series map:
D5C
100.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D5C Engine
Caterpillar 5.0L 6-cyl diesel
Engine details ...
Caterpillar D5C Transmissions
3-speed power shift
hydrostatic
Transmission details ...
Caterpillar D5C Power
Engine (gross)100 hp
74.6 kW
Engine (net)91 hp
67.9 kW
Mechanical
Drivecrawler
Final drivesspur gear (gear drive)
 outboard planetary (hydro)
Photos
No photos of the Caterpillar D5C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel41.4 gal
156.7 L
Hydraulic system15 gal
56.8 L
Hydraulics
Capacity15 gal
56.8 L
Pressure2500 psi
172.4 bar
Pump flow17.6 gpm
66.6 lpm
Dimensions & Tracks
Weight19447 lbs
8821 kg
18-inch tracks
Full dimensions and tracks ...
Caterpillar D5C attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps55
 90 *With cab.
Battery CCA900
Battery volts12
References
D5C Series III references literature
D5C Series III Track-Type Tractor published in 1994, by Caterpillar
D5C Series III Track-Type Tractor published in 1997, by Caterpillar
