Tractors > Caterpillar > D5C

Caterpillar D5C



No photo available
1991 - 2001
Model year
Bulldozer
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D5C Engine
Caterpillar 5.2L 4-cyl diesel
Engine details ...
Caterpillar D5C Transmission
3-speed power shift
Transmission details ...
Caterpillar D5C Power
Engine (gross)95 hp
70.8 kW
Engine (net)90 hp
67.1 kW
Mechanical
Drivecrawler
Final drivesspur gear
Four-post ROPS. Cab available with heat.
Photos
No photos of the Caterpillar D5C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel44 gal
166.5 L
Hydraulic system15 gal
56.8 L
Hydraulics
Typeopen center
Capacity15 gal
56.8 L
Pressure2500 psi
172.4 bar
Pump flow14.5 gpm
54.9 lpm
Dimensions & Tracks
Weight15800 to 19800 pounds
18-inch tracks
Full dimensions and tracks ...
Caterpillar D5C attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps40
 75 *With cab.
Battery volts12
References
D5C references literature
D5C Track-Type Tractor published in 1991, by Caterpillar
