Tractors > Caterpillar > D6T

Caterpillar D6T



Caterpillar D6T tractor photo
2006 - 2019
Model year
Bulldozer
Series map:
D6T
213.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6T Engine
Caterpillar 8.8L 6-cyl diesel
Engine details ...
Caterpillar D6T Transmission
3-speed power shift
Transmission details ...
Caterpillar D6T Power
Engine (gross)213 hp
158.8 kW
Engine (net)185 hp
138.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel112 gal
423.9 L
Hydraulic system13.6 gal
51.5 L
Hydraulics
Typeload sensing variable displacement
Capacity13.6 gal
51.5 L
Pressure3147 psi
217.0 bar
 3545 psi (VPAT)
244.4 bar
Pump flow49.9 gpm
188.9 lpm
Steering flow47.3 gpm
179.0 lpm
Steering press.6048 psi
417.0 bar
Dimensions & Tracks
Weight32576 to 41298 pounds
Tracks
Full dimensions and tracks ...
Caterpillar D6T attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps95
 150 OptOptional
Batteries2
Battery volts12
References
D6T references literature
D6T Track-Type Tractor published in 2006, by Caterpillar
