Tractors > Caterpillar > D6R Series III

Caterpillar D6R Series III



Caterpillar D6R Series III tractor photo
1995 - 2006
Model year
Bulldozer
Series map:
D6R
213.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6R Engine
Caterpillar 8.8L 6-cyl diesel
Engine details ...
Caterpillar D6R Transmission
3-speed power shift
Transmission details ...
Caterpillar D6R Power
Engine (gross)213 hp
158.8 kW
Engine (net)185 hp
138.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel112 gal
423.9 L
Hydraulic system13.6 gal
51.5 L
Hydraulics
Typeload sensing variable displacement
Capacity13.6 gal
51.5 L
Pressure6092 psi
420.0 bar
Pump flow57.3 gpm
216.9 lpm
Dimensions & Tracks
Weight32426 to 41148 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D6R attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps95
Batteries2
Battery volts12
References
D6R Series III references literature
D6R Series III Track-Type Tractor published in 2005, by Caterpillar
