Tractors > Caterpillar > D6R Series II

Caterpillar D6R Series II



Caterpillar D6R Series II tractor photo
1995 - 2006
Model year
Bulldozer
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6R Engine
Caterpillar 8.8L 6-cyl diesel
Engine details ...
Caterpillar D6R Transmission
3-speed power shift
Transmission details ...
Caterpillar D6R Power
Engine (gross)189 hp
140.9 kW
Engine (net)165 hp
123.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel101 gal
382.3 L
Hydraulic system12.5 gal
47.3 L
Hydraulics
Capacity12.5 gal
47.3 L
Pressure2799 psi
193.0 bar
 6092 psi (differential steer)
420.0 bar
Pump flow56 gpm
212.0 lpm
 57.3 gpm (differential steering)
216.9 lpm
Dimensions & Tracks
Weight32426 to 41062 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D6R attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps70
 125 OptOptional
Batteries2
Battery volts12
References
D6R Series II references literature
D6R Series II Track-Type Tractor published in 2002, by Caterpillar
