Tractors > Caterpillar > D6R

Caterpillar D6R



Caterpillar D6R tractor photo
1995 - 2006
Model year
Bulldozer
Series map:
D6R
179.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6R Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Caterpillar D6R Transmission
3-speed power shift
Transmission details ...
Caterpillar D6R Power
Engine (gross)179 hp
133.5 kW
Engine (net)165 hp
123.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel101 gal
382.3 L
Hydraulic system20 gal
75.7 L
Hydraulics
Typeload sensing variable displacement
Capacity20 gal
75.7 L
Pressure2800 psi
193.1 bar
 6090 psi (differential steer)
419.9 bar
Pump flow50.2 gpm
190.0 lpm
 51.8 gpm (differential steer)
196.1 lpm
Dimensions & Tracks
Weight32600 to 45600 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D6R attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps70
Batteries2
Battery CCA750
Battery volts12
Battery AH100
References
D6R references literature
D6R Track-Type Tractor published in 1996, by Caterpillar
