Tractors > Caterpillar > D6H Series II

Caterpillar D6H Series II



No photo available
1985 - 1995
Model year
Bulldozer
Series map:
D6H
179.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6H Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Caterpillar D6H Transmissions
6-speed direct drive
3-speed power shift
Transmission details ...
Caterpillar D6H Power
Engine (gross)179 hp
133.5 kW
Engine (net)165 hp
123.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel89 gal
336.9 L
Hydraulic system12.5 gal
47.3 L
Hydraulics
Typeload sensing
Capacity12.5 gal
47.3 L
Pressure2871 psi
198.0 bar
Pump flow46.7 gpm
176.8 lpm
 51.8 gpm (differential steer)
196.1 lpm
Dimensions & Tracks
Weight32500 to 39325 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D6H attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps50
References
D6H Series II references literature
D6H Series II Track-Type Tractor published in 1990, by Caterpillar
D6H Series II Track-Type Tractor published in 1992, by Caterpillar
