Caterpillar D6H



Caterpillar D6H tractor photo
1985 - 1995
Model year
Bulldozer
Series map:
D6H
179.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D6H Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Caterpillar D6H Transmissions
6-speed direct drive
3-speed power shift
Transmission details ...
Caterpillar D6H Power
Engine (gross)179 hp
133.5 kW
Engine (net)165 hp
123.0 kW
Mechanical
Drivecrawler
Final drivessingle-reduction planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D6H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel85 gal
321.7 L
Hydraulic system19.2 gal
72.7 L
Hydraulics
Capacity19.2 gal
72.7 L
Pump flow44 gpm
166.5 lpm
Dimensions & Tracks
Weight30359 to 37377 pounds
18-inch tracks
Full dimensions and tracks ...
Caterpillar D6H attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps35
 50 OptOptional
References
D6H references literature
D6H Track-type Tractor published in 1985, by Caterpillar
D6H The shape of the future... published in 1985, by Caterpillar
