Caterpillar SxS D9H

1974 - 1977

Bulldozer

Production
Manufacturer	Caterpillar
Bulldozer
Built in Peoria, Illinois, USA
Total built	13
The SxS D9H consisted of two D9H tractors connected side-by-side behind a single blade. The operator controlled both machines from the left-side tractor using pneumo-hydraulic controls. The left tractor was fitted with a 12 CFM compressor and two air supply tanks.

Variants
DD9H	tandem D9s
SxS D9H	side-by-side D9Hs

Caterpillar SxS D9H Engine
Caterpillar 24.1L 6-cyl diesel
Fuel tank	460 gal*Combined capacity of both machines. 1741.1 L
Engine details ...

Caterpillar SxS D9H Transmission
3-speed power shift
Transmission details ...

Caterpillar SxS D9H Power
Engine (net)	820 hp 611.5 kW

Mechanical
Drive	crawler
Final drives	planetary
Cab optional with available air-conditioning.

Photos
No photos of the Caterpillar SxS D9H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.

Dimensions & Tracks
Weight	183900 to 190500 pounds
24-inch tracks
Full dimensions and tracks ...

Caterpillar SxS D9H attachments
blade
Attachment details ...

Electrical
Charging system	alternator
Charging amps	50
Batteries	4
Battery volts	12
Battery AH	200

References

D7G - D8K - D9H published by Caterpillar
Compact Sales Kit published in 1985, by Caterpillar
