Caterpillar D7H Series II



No photo available
1985 - 1995
Model year
Bulldozer
Series map:
D7H
247.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D7H Engine
Caterpillar 10.5L 6-cyl diesel
Engine details ...
Caterpillar D7H Transmissions
6-speed direct drive
3-speed power shift
Transmission details ...
Caterpillar D7H Power
Engine (gross)247 hp
184.2 kW
Engine (net)230 hp
171.5 kW
Mechanical
Drivecrawler
Final drivesdouble-reduction planetary
ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D7H are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel129 gal
488.3 L
Hydraulic system17.5 gal
66.2 L
Hydraulics
Typeopen center
Capacity17.5 gal
66.2 L
Pressure3300 psi
227.5 bar
Pump flow46.2 gpm
174.9 lpm
Dimensions & Tracks
Weight44154 to 60047 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D7H attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps50
Battery volts12
References
D7H Series II references literature
D7H Series II Track-Type Tractor published in 1990, by Caterpillar
D7H Series II Track-Type Tractor published in 1993, by Caterpillar*
*Publication contains known errors.
