Tractors > Caterpillar > D8R

Caterpillar D8R



Caterpillar D8R tractor photo
1995 - 2004
Model year
Bulldozer
Series map:
D8R
328.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D8R Engine
Caterpillar 14.6L 6-cyl diesel
Engine details ...
Caterpillar D8R Transmission
3-speed power shift
Transmission details ...
Caterpillar D8R Power
Engine (gross)328 hp
244.6 kW
Engine (net)305 hp
227.4 kW
Mechanical
Drivecrawler
Final drivesdouble reduction planetary
Four-post ROPS. Cab available with heat and air-conditioning.
Photos
No photos of the Caterpillar D8R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel165 gal
624.5 L
Hydraulic system19 gal
71.9 L
Hydraulics
Typeload sensing
Capacity19 gal
71.9 L
Pressure3500 psi
241.3 bar
Pump flow79 gpm
299.0 lpm
Dimensions & Tracks
Weight60454 to 82850 pounds
22-inch tracks
Full dimensions and tracks ...
Caterpillar D8R attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps50
Batteries4
Battery volts12
References
D8R references literature
D8R Track-Type Tractor published in 1997, by Caterpillar
