International Harvester 175C
|
|
| Production | |
| Manufacturer | International Harvester |
| Crawler Loader | |
| International Harvester 175C Engine | |
| International Harvester 7.6L 6-cyl diesel | |
 Engine details ... |
| International Harvester 175C Transmission | |
| 4-speed power shift | |
 Transmission details ... |
| International Harvester 175C Power | |
| Engine (net) | 130 hp 96.9 kW |
| Mechanical | |
| Drive | crawler |
| Final drives | planetary |
| Four-post ROPS. | |
| Photos | |
| No photos of the International Harvester 175C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 60 gal 227.1 L |
| Hydraulic system | 24 gal 90.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 24 gal 90.8 L |
| Pressure | 1000 psi 69.0 bar |
| Pump flow | 52 gpm 196.8 lpm |
| Dimensions & Tracks | |
| Weight | 30655 lbs 13905 kg |
| 15-inch tracks | |
 Full dimensions and tracks ... | |
| International Harvester 175C attachments | |
| front-end loader | |
 Attachment details ... |
| 175C Serial Numbers | |
| 1972 | 501 |
| 1973 | 1204 |
| 1974 | 1888 |
| 1975 | 2489 |
| 1976 | 2791 |
| 1977 | 2843 |
| 1978 | 3171 |
| 1979 | 3591 |
| 1980 | 3726 |
| 1981 | 3756 |
| 1982 | 3849 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 35 |
| Batteries | 4 |
| Battery volts | 6 |
| References | |
 | |
| 175C Loader published in 1972, by International Harvester | |
| 175C PAY loader Specifications published in 1977, by International Harvester |
