Caterpillar D11T



Caterpillar D11T tractor photo
2007 - 2020
Bulldozer
Series map:
D11T
935.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D11T Engine
Caterpillar 32.1L 12-cyl diesel
Engine details ...
Caterpillar D11T Transmission
3-speed power shift
Transmission details ...
Caterpillar D11T Power
Engine (gross)935 hp
697.2 kW
Engine (net)850 hp
633.8 kW
Mechanical
Drivecrawler
Final drivestwo-stage planetary
Cab standard with available air-conditioning.
Photos
No photos of the Caterpillar D11T are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel425 gal
1608.6 L
 505 galOptOptional
1911.4 L
Hydraulic system64 gal
242.2 L
Hydraulics
Typeopen center
Capacity64 gal
242.2 L
Pressure3525 psi
243.0 bar
Pump flow164 gpm
620.7 lpm
Dimensions & Tracks
Weight163200 to 230100 pounds
28-inch tracks
Full dimensions and tracks ...
Caterpillar D11T attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps100
Batteries4
Battery volts12
Battery AH190
References
D11T references literature
Move More - Cat Large Dozers published in 2014, by Caterpillar
D11T/D11T CD Track-Type Tractor published in 2007, by Caterpillar
D11T/D11T CD Dozer published in 2016, by Caterpillar
