Tractors > Caterpillar > D10N

Caterpillar D10N



No photo available
1987 - 1996
Bulldozer
Series map:
D10N
557.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D10N Engine
Caterpillar 27.0L 12-cyl diesel
Engine details ...
Caterpillar D10N Transmission
3-speed power shift
Transmission details ...
Caterpillar D10N Power
Engine (gross)557 hp
415.4 kW
Engine (net)520 hp
387.8 kW
Mechanical
Drivecrawler
Final drivestwo-stage planetary
Four-post ROPS. Cab available with air-conditioning.
Photos
No photos of the Caterpillar D10N are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel270.3 gal
1023.1 L
Hydraulic system28.5 gal
107.9 L
Hydraulics
Capacity28.5 gal
107.9 L
Pressure2800 psi
193.1 bar
Pump flow107.8 gpm
408.0 lpm
Dimensions & Tracks
Weight103161 to 141898 pounds
24-inch tracks
Full dimensions and tracks ...
Caterpillar D10N attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps75
Batteries2
Battery volts12
Battery AH244
References
D10N references literature
D10N Track-Type Tractor published in 1990, by Caterpillar
