Tractors > Caterpillar > D3C Series II

Caterpillar D3C Series II



No photo available
1987 - 2001
Model year
Bulldozer
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D3C Engine
Caterpillar 5.2L 4-cyl diesel
Engine details ...
Caterpillar D3C Transmission
3-speed power shift
Transmission details ...
Caterpillar D3C Power
Engine (gross)75 hp
55.9 kW
Engine (net)69 hp
51.5 kW
Mechanical
Drivecrawler
Final drivesspur gear
Four-post ROPS. Cab available with heat and air-conditioning.
Photos
No photos of the Caterpillar D3C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel31.9 gal
120.7 L
Hydraulic system15 gal
56.8 L
Hydraulics
Typeopen center
Capacity15 gal
56.8 L
Pressure2500 psi
172.4 bar
Pump flow14.5 gpm
54.9 lpm
Dimensions & Tracks
Weight12270 to 17170 pounds
14-inch tracks
Full dimensions and tracks ...
Caterpillar D3C attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps40
Battery volts12
References
D3C Series II references literature
D3C Series II Track-Type Tractor published in 1988, by Caterpillar
