Caterpillar D3C



No photo available
1987 - 2001
Model year
Bulldozer
Series map:
D3C
73.0hp
Production
ManufacturerCaterpillar
Bulldozer
Caterpillar D3C Engine
Caterpillar 5.2L 4-cyl diesel
Engine details ...
Caterpillar D3C Transmission
3-speed power shift
Transmission details ...
Caterpillar D3C Power
Engine (gross)73 hp
54.4 kW
Engine (net)67 hp
50.0 kW
Mechanical
Drivecrawler
Final drivesspur gear
Four-post ROPS. Cab available with heat and air-conditioning.
Photos
No photos of the Caterpillar D3C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel30.6 gal
115.8 L
Hydraulic system15 gal
56.8 L
Hydraulics
Typeopen center
Capacity15 gal
56.8 L
Pressure2500 psi
172.4 bar
Pump flow14.5 gpm
54.9 lpm
Dimensions & Tracks
Weight11486 to 16801 pounds
14-inch tracks
Full dimensions and tracks ...
Caterpillar D3C attachments
blade
Attachment details ...
Electrical
Charging systemalternator
Charging amps40
Battery volts12
References
D3C references literature
D3C Track-Type Tractor published in 1988, by Caterpillar
