Production | |
Manufacturer | J.I. Case |
Crawler Loader |
J.I. Case 455C Engine | |
Case 3.9L 4-cyl diesel | |
Engine details ... |
J.I. Case 455C Transmission | |
4-speed power shift | |
Transmission details ... |
J.I. Case 455C Power | |
Engine (gross) | 71 hp 52.9 kW |
Engine (net) | 63 hp 47.0 kW |
Mechanical | |
Drive | crawler |
Final drives | bull gear |
Hydraulic disc brakes | |
Four-post ROPS. |
Photos | |
No photos of the J.I. Case 455C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity | |
Fuel | 27.5 gal 104.1 L |
Hydraulic system | 8.5 gal 32.2 L |
Hydraulics | |
Type | open center |
Capacity | 8.5 gal 32.2 L |
Pressure | 2500 psi 172.4 bar |
Pump flow | 22 gpm 83.3 lpm |
Dimensions & Tracks | |
Weight | 14433 lbs 6546 kg |
14-inch tracks | |
Full dimensions and tracks ... |
J.I. Case 455C attachments | |
front-end loader | |
Attachment details ... |
455C Serial Numbers | |
1983 | 3075913 |
1984 | 3076101 |
1985 | 3080001 |
FAQ: How to read a serial number table. |
Electrical | |
Charging system | alternator |
Charging amps | 42 |
References | |
455C Loader published in 1983, by J.I. Case | |
Utility Equipment published in 1988, by J.I. Case |
