John Deere 544B
Series map:
544B
644B
115.0hp
160.0hp
Production Manufacturer John Deere
Wheel Loader
John Deere 544B Power Engine (gross) 115 hp85.8 kW
Engine (net) 105 hp78.3 kW
Mechanical Four-wheel drive Final drives inboard planetary
Articulated power steering Hydraulic wet disc brakes Four-post ROPS with canopy. Cab optional.
Photos No photos of the John Deere 544B are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Hydraulics Type open center
Pressure 2250 psi155.1 bar
Pump flow 44.5 gpm168.4 lpm
Steering flow 26.5 gpm100.3 lpm
Steering press. 2350 psi162.0 bar
Electrical Charging system alternator
Batteries 2
Battery CCA 625
Battery volts 12
References Construction Purchasing Guide published in 1974, by John Deere Industrial Equipment Division published in 1980, by John Deere
