John Deere 544D



John Deere 544D tractor photo
1985 - 1986
Wheel Loader
Series map:
444D
544D
644D
97.0hp
122.0hp
165.0hp
Production
ManufacturerJohn Deere
Wheel Loader
John Deere 544D Engine
John Deere 6.8L 6-cyl diesel
Fuel tank50 gal
189.2 L
Engine details ...
John Deere 544D Transmission
4-speed power shift
Transmission details ...
John Deere 544D Power
Engine (gross)122 hp
91.0 kW
Engine (net)115 hp
85.8 kW
Mechanical
Four-wheel drive
Final drivesinboard planetary
Articulated power steering
Hydraulic wet disc brakes
Four-post ROPS with canopy. Cab optional with available air-conditioning.
Photos
No photos of the John Deere 544D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2625 psi
181.0 bar
Pump flow49.2 gpm
186.2 lpm
Dimensions & Tires
Wheelbase102.1 inches
259 cm
Weight22660 lbs
10278 kg
Front tire17.5-25
Rear tire17.5-25
Full dimensions and tires ...
John Deere 544D attachments
front-end loader
Attachment details ...
Electrical
Charging systemalternator
ROPS Charging amps42
Cab Charging amps90
Battery CCA625
Battery volts12
References
544D references literature
Construction Equipment Purchasing Guide published in 1986, by John Deere
