Allis Chalmers HD-4


Allis Chalmers HD-4 tractor photo
1966 - 1969
Industrial Crawler tractor
Series map:
HD-4
52.0hp
Production
ManufacturerAllis Chalmers
Industrial Crawler tractor
Variants
H-4gasoline
HD-4diesel
HD-4 Loaderloader-crawler
Allis Chalmers HD-4 Engine
Allis Chalmers 3.3L 4-cyl diesel
Fuel tank18 gal
68.1 L
Engine details ...
Allis Chalmers HD-4 Power
Engine (gross)52 hp
38.8 kW
Mechanical
Drivecrawler
External band brakes
Open operator station.
Photos
No photos of the Allis Chalmers HD-4 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure1625 psi
112.0 bar
Pump flow15 gpm
56.8 lpm
 25 gpmOptOptional
94.6 lpm
Dimensions & Tracks
Weight8500 lbs
3855 kg
12-inch tracks
Full dimensions and tracks ...
HD-4 Serial Numbers
Location:Serial number on the front of the crawler, below the grill.
References
HD-4 references literature
H-4 & HD-4 Crawler Tractors published in 1969, by Allis Chalmers
