John Deere 350C Loader
1974 - 1985 Crawler Loader
Series map:
350C Loader
46.0hp
Production Manufacturer John Deere
Crawler Loader
John Deere 350C Loader Power Engine (gross) 46 hp34.3 kW
Engine (net) 42 hp31.3 kW
Mechanical Drive crawler
Steering clutch-brake system
Contracting band brakes Four-post ROPS with canopy. Cab optional.
Photos No photos of the John Deere 350C Loader are currently available. To submit yours, email it to Peter@TractorData.com . Photos may only be used with the permission of the original photographer.
Capacity Fuel 22 gal83.3 L
Hydraulic system 6.4 gal (reservoir)24.2 L
12.5 gal (loader)47.3 L
Hydraulics Type open center
Capacity 6.4 gal (reservoir)24.2 L
12.5 gal (loader)47.3 L
Pressure 2250 psi155.1 bar
Total flow 15 gpm56.8 lpm
23 gpmOpt Optional 87.1 lpm
Power Take-off (PTO) Rear PTO optional
Rear PTO Type 540
350C Loader Serial Numbers Location: Serial number plate located on the front of the seat frame of the John Deere 350.
References Utility Purchasing Guide published in 1978, by John Deere Utility Purchasing Guide published in 1979, by John Deere Industrial Equipment Division published in 1980, by John Deere Utility Equipment Purchasing Guide published in 1981, by John Deere
