J.I. Case 648


J.I. Case 648 tractor photo
1980 - 1988
600 Series
Industrial tractor
Series map:
648
18.0hp
Production
ManufacturerJ.I. Case
Industrial tractor
J.I. Case 648 Engine
Onan 0.8L 2-cyl gasoline
Engine details ...
J.I. Case 648 Power
Engine18 hp
13.4 kW
Mechanical
Two-wheel drive
Power steering
Mechanical band brakes
Open operator station.
Capacity
Fuel5 gal
18.9 L
Hydraulic system3.25 gal (loader tractor)
12.3 L
 5 gal (backhoe loader)
18.9 L
Hydraulics
Typeopen center
Capacity3.25 gal (loader tractor)
12.3 L
 5 gal (backhoe loader)
18.9 L
Pressure2500 psi
172.4 bar
Pump flow7 gpm
26.5 lpm
Tractor hitch
Rear Type0 OptOptional
Typesleeve hitch OptOptional
Dimensions & Tires
Wheelbase48 inches
121 cm
Weight1273 to 2750 pounds
Front tire18x8.50-8
Rear tire26x12.00-12
Full dimensions and tires ...
J.I. Case 648 attachments
44" mid-mount mower deck
48" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
648 Serial Numbers
Location:Serial number plate on the left side of tractor, ahead of the steering column.
Electrical
Groundnegative
Charging systemflywheel alternator
Charging amps15
Charging volts12
Battery volts12
Battery AH32
References
648 references literature
648 Loader/Tractor Loader/Backhoe published by J.I. Case
648 Compact Loader/Tractor published in 1980, by J.I. Case
648 Wheel Loader Operator's Manual (9-8171) published in 1983
Case Planning Guide published in 1980, by J.I. Case
Case Lawn/Garden Tractors published in 1984, by J.I. Case
Lawn & Garden Tractors published in 1984, by Ingersoll
