Tractors > J.I. Case > 648

J.I. Case 648 Engine



J.I. Case 648 tractor photo
1980 - 1988
600 Series
Industrial tractor
Series map:
648
18.0hp
Engine Detail
Onan B48M
gasoline
2-cylinder
air-cooled
Displacement47.7 ci
0.8 L
Bore/Stroke3.25x2.875 inches
83 x 73 mm
Power18 hp
13.4 kW
Compression6.6:1
Rated RPM3600
Starterelectric
Starter volts12
SparkplugChampion RH18Y
Sparkplug gap0.025 inches
0.635 mm
Engine Oil
648 gasoline engine oil chart
Oil capacity2 qts
1.9 L
