John Deere 440A


John Deere 440A tractor photo
1967 - 1970
Skidder
Series map:
440A
75.5hp
Production
ManufacturerJohn Deere
Skidder
FactoriesDubuque, Iowa, USA
 Welland, Ontario, Canada
John Deere 440A Engine
John Deere 3.6L 4-cyl diesel
Syncro Fuel tank24 gal
90.8 L
PS Fuel tank42 gal
159.0 L
Engine details ...
John Deere 440A Transmissions
8-speed partially synchronized
8-speed full power shift
Transmission details ...
John Deere 440A Power
Engine (gross)75.5 hp
56.3 kW
Engine (net)70 hp
52.2 kW
Mechanical
Four-wheel drive
Final drivesplanetary
Differential lockhydraulic front
Articulated power steering
Disc brakes
Four-post ROPS.
Photos
No photos of the John Deere 440A are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Wheelbase89 inches
226 cm
Weight11900 to 14000 pounds
Front tire16.9-30
Rear tire16.9-30
Full dimensions and tires ...
Electrical
Charging systemalternator
Batteries2
Battery volts12
Battery AH70
References
440A references literature
JD440 Series-A Skidder published by John Deere
