Production | |
Manufacturer | Massey Ferguson |
Industrial tractor |
Variants | |
50C | backhoe-loader |
Massey Ferguson 50C Engine | |
Perkins 3.9L 4-cyl diesel | |
Engine details ... |
Massey Ferguson 50C Transmissions | |
6-speed manual shuttle | |
4-speed power shuttle with torque converter | |
Transmission details ... |
Massey Ferguson 50C Power | |
Engine (gross) | 67.5 hp 50.3 kW |
Engine (net) | 62 hp 46.2 kW |
Mechanical | |
Two-wheel drive | |
Final drives | outboard planetary |
Differential lock | mechanical rear |
Power steering | |
Differential mechanical wet disc brakes | |
Two-post ROPS. Optional canopy. |
Photos | |
No photos of the Massey Ferguson 50C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Capacity | |
Fuel | 18 gal 68.1 L |
Hydraulic system | 7 gal (reservoir) 26.5 L |
  | 10 gal (loader) 37.9 L |
  | 15 gal (backhoe) 56.8 L |
Steering | 2 qts 1.9 L |
Hydraulics | |
Type | open center |
Capacity | 7 gal (reservoir) 26.5 L |
  | 10 gal (loader) 37.9 L |
  | 15 gal (backhoe) 56.8 L |
Pressure | 2000 psi 137.9 bar |
Total flow | 29 gpm 109.8 lpm |
Steering cap. | 2 qts 1.9 L |
Power Take-off (PTO) | |
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Engine RPM | 540@1700 |
Dimensions & Tires | |
Wheelbase | 84 inches 213 cm |
Weight | 5200 lbs 2358 kg |
Front tire | 11Lx16 |
Rear tire | 16.9x24 |
Full dimensions and tires ... |
Massey Ferguson 50C attachments | |
front-end loader | |
Attachment details ... |
50C Serial Numbers | |
Location: | Serial number plate located below steering column. |
1976 | 9A250640 |
1977 | 9A257837 |
1978 | 9A280301 |
1979 | 9A300200 |
1980 | 9A326169 |
1981 | 9A339334 |
1982 | 9A350584 |
FAQ: How to read a serial number table. |
Electrical | |
Ground | negative |
Charging system | alternator |
Charging amps | 37 |
Battery volts | 12 |
Battery AH | 180 |
References | |
Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1977, by Massey Ferguson | |
Industrial Tractors published in 1977, by Massey Ferguson | |
Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1979, by Massey Ferguson | |
Industrial Machinery Buyer's Guide published in 1980, by Massey Ferguson | |
Backhoe Loaders - Tractor Loaders - Industrial Tractors published in 1981, by Massey Ferguson |
