Ford 340B
| | 1984 - 1987 |
| Industrial tractor |
|
Series map:
340B
540B
48.0hp
60.0hp
| Production |
| Manufacturer | Ford
|
| Industrial tractor |
| Ford 340B Power |
| Engine (gross) | 52 hp
38.8 kW
|
| Engine | 48 hp
35.8 kW
|
| PTO (claimed) | 44 hp
32.8 kW
|
| Mechanical |
| Two-wheel drive |
| Differential lock | standard
|
| Steering | hydrostatic power
|
| Differential mechanical wet disc brakes |
| Two-post ROPS. Four-post ROPS canopy optional. High-clearance canopy with backhoe. |
| Capacity |
| Fuel | 16 gal
60.6 L
|
| Hydraulic system | 11 gal (loader)
41.6 L
|
| Steering | 5 qts
4.7 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 11 gal (loader)
41.6 L
|
| Pressure | 2500 psi
172.4 bar
|
| Total flow | 5.6 gpm
21.2 lpm
|
| | 8.5 gpm (independent PTO)
32.2 lpm
|
| | 21.5 gpm (loader/backhoe)
81.4 lpm
|
| Steering flow | 5.9 gpm
22.3 lpm
|
| Steering cap. | 5 qts
4.7 L
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 2,040 lbs
925 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| | independent
|
| Rear PTO Type | 540
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 32
|
| | 51 (optional)
|
| Battery CCA | 750
|
| Battery volts | 12
|
| Battery AH | 128
|
| References |
 |
| 340B - 540B published in 1986, by Ford |
| Industrial Buyer's Guide 1984-1985 published by Ford |
| 1986 Industrial Buyer's Guide published by Ford |
