J.I. Case 480B


J.I. Case 480B tractor photo
1971 - 1977
Industrial tractor
Series map:
480B
41.5hp
Production
ManufacturerJ.I. Case
Industrial tractor
J.I. Case 480B Engines
J.I. Case 3.1L 4-cyl diesel
J.I. Case 2.4L 4-cyl gasoline
Engine details ...
J.I. Case 480B Transmissions
4-speed mechanical shuttle
8-speed mechanical shuttle
Transmission details ...
J.I. Case 480B Power
Engine (gross)41.5 hp
30.9 kW
Engine (net)37 hp
27.6 kW
Mechanical
Two-wheel drive
Final drivesspur gear
Power steering
Mechanical disc brakes
Open operator station. Optional Four-post ROPS and cab.
Capacity
Fuel22 gal
83.3 L
Hydraulic system11 gal
41.6 L
Hydraulics
Typeopen center
Capacity11 gal
41.6 L
Pump flow10 gpm (hitch)
37.9 lpm
 21 gpm (loader/backhoe)
79.5 lpm
Dimensions & Tires
Wheelbase78.4 inches
199 cm
Weight3625 to 8950 pounds
Front tire7.50x16
Rear tire13.6x24
Full dimensions and tires ...
References
480B references literature
480 B Construction King published in 1972, by J.I. Case
1975 Spring Buyers Guide published by J.I. Case
Time-saving experts published in 1975, by J.I. Case
