Ford 2000
| | 1960 - 1964 |
|
| 2130 Series | | Industrial tractor |
|
| Production |
| Manufacturer | Ford
|
| Industrial tractor |
| Variants |
| 21301 | 4-speed, no 3-point or PTO
|
| 21302 | 4-speed, no PTO
|
| 21303 | 4-speed
|
| 21304 | Select-O-Speed, no 3-point or PTO
|
| 21305 | Select-O-Speed
|
| 21306 | Select-O-Speed, 540/1000 PTO
|
| 21313 | LCG
|
| Ford 2000 Power |
| Engine (gross) | 48.4 hp
36.1 kW
|
| Mechanical |
| Two-wheel drive |
| Steering | power assist
|
| Differential mechanical shoe brakes |
| Open operator station. |
| Capacity |
| Fuel | 13 gal
49.2 L
|
| Hydraulic system | 2 gal
7.6 L
|
| Hydraulics |
| Type | open center
|
| Capacity | 2 gal
7.6 L
|
| Pressure | 2000 psi
137.9 bar
|
| Total flow | 4 gpm
15.1 lpm
|
| Steering flow | 5 gpm
18.9 lpm
|
| Steering press. | 800 psi
55.2 bar
|
| Tractor hitch |
| Rear Type | I
|
| Rear lift (at ends) | 2360 lbs
1070 kg
|
| Power Take-off (PTO) |
| Rear PTO | transmission
|
| | independent *Independent with Select-o-Speed transmission.
|
| Rear PTO Type | 540
|
| Engine RPM | 540@1485 (gear)
|
| | 540@1750 (SoS)
|
| Electrical |
| Charging system | generator
|
| Charging amps | 20
|
| Battery volts | 6 (gas)
|
| | 12 (diesel)
|
| Battery AH | 80 (gas)
|
| | 135 (diesel)
|
| References |
 |
| Industrial Tractors and Equipment published in 1964, by Ford |
| Ford for Snow Removal published in 1964 |
