International Harvester 2424
|
|
| Production | |
| Manufacturer | International Harvester |
| Industrial tractor | |
| Variants | |
| 424 | farm tractor |
| 2424 | industrial |
| 2424 Lo-Boy | low-profile |
| International Harvester 2424 Engines | |
| International Harvester 2.4L 4-cyl gasoline | |
| International Harvester 2.5L 4-cyl diesel | |
 Engine details ... |
| International Harvester 2424 Transmissions | |
| 8-speed gear | |
| 8-speed shuttle | |
 Transmission details ... |
| International Harvester 2424 Power | |
| Engine (gross) | 47 hp 35.0 kW |
| PTO (claimed) | 36 hp 26.8 kW |
| Mechanical | |
| Two-wheel drive | |
| Steering | manual |
| Steering | power OptOptional |
| Disc brakes | |
| Open operator station. | |
| Capacity | |
| Fuel | 14 gal 53.0 L |
| Hydraulic system | 3 gal 11.4 L |
| Hydraulics | |
| Type | open center |
| Capacity | 3 gal 11.4 L |
| Gas Pump flow | 4.5 gpm 17.0 lpm |
| Diesel Pump flow | 6.8 gpm 25.7 lpm |
| 9 gpm*Pump with power steering, replaced the 4.5 or 6.8 GPM pump. 34.1 lpm | |
| 17 gpm*Optional additional crank-shaft mounted pump. 64.3 lpm | |
| Tractor hitch | |
| Rear Type | I OptOptional |
| Power Take-off (PTO) | |
| Rear PTO | transmission OptOptional |
| live OptOptional | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2000 |
| Dimensions & Tires | |
| Wheelbase | 70 inches 177 cm |
| Weight | 3250 to 3370 pounds |
| Front tire | 5.50-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| 2424 Serial Numbers | |
| 1964 | 501 |
| 1965 | 517 |
| 1966 | 1930 |
| 1967 | 3316 |
FAQ: How to read a serial number table. | |
| References | |
 | |
| Buyer's Guide 1965 published by International Harvester | |
| Buyer's Guide 1967 published by International Harvester |
