Ford 545C


Ford 545C tractor photo
1990 - 1991
C Series
Industrial tractor
Series map:
445C
545C
56.0hp
67.0hp
Production
ManufacturerFord
Industrial tractor
Ford 545C Engine
Ford 3.3L 3-cyl diesel
Engine details ...
Ford 545C Transmissions
6-speed manual reversing
4-speed torque converter
8-speed torque converter
Transmission details ...
Ford 545C Power
Engine (gross)67 hp
50.0 kW
Engine (net)62 hp
46.2 kW
PTO (claimed)53.7 hp
40.0 kW
Mechanical
Two- or four-wheel drive
Power steering
Wet disc brakes
Two-post ROPS with available canopy. Four-post ROPS/FOPS optional.
Capacity
Fuel16 gal
60.6 L
Hydraulic system9.1 gal (loader)
34.4 L
Steering4 qts
3.8 L
Hydraulics
Typeopen center
Capacity9.1 gal (loader)
34.4 L
Pressure2450 psi
168.9 bar
Pump flow5.6 gpm (hitch)
21.2 lpm
 8.5 gpm (hitch optional)
32.2 lpm
 26 gpm (loader pump)
98.4 lpm
Steering flow5.9 gpm
22.3 lpm
Steering cap.4 qts
3.8 L
Tractor hitch
Rear TypeI
Controlposition control and top-link draft sensing
Rear lift3080 lbs
1397 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@1800
Dimensions & Tires
Wheelbase81 inches
205 cm
Weight8610 to 8830 pounds
Front tire7.50-16
Rear tire16.9-24
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Charging amps55
Battery CCA750
Battery volts12
Battery AH128
References
545C references literature
Tractor Loader 545C published in 1989, by Ford
Construction Equipment Buyer's Guide published in 1989, by Ford
