John Deere 500
| | 1964 - 1965 |
| Industrial tractor |
|
Series map:
400
500
600
59.0hp
80.0hp
101.2hp
| Production |
| Manufacturer | John Deere
|
| Industrial tractor |
| Variants |
| 3020 | farm tractor
|
| John Deere 500 Power |
| Engine | 80 hp
59.7 kW
|
| Mechanical |
| Two-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Open operator station. |
| Capacity |
| Fuel | 25 gal
94.6 L
|
| Hydraulic system | 9.5 gal (collar shift)
36.0 L
|
| | 14 gal (power shift)
53.0 L
|
| Hydraulics |
| Capacity | 9.5 gal (collar shift)
36.0 L
|
| | 14 gal (power shift)
53.0 L
|
| Pressure | 2000 psi
137.9 bar
|
| Valves | 1 or 2
|
| Total flow | 24.5 gpm
92.7 lpm
|
| Tractor hitch |
| Rear Type | II OptOptional
|
| Power Take-off (PTO) |
| Rear PTO | independent OptOptional
|
| Rear PTO Type | 540/1000
|
| Front PTO | optional
|
| Front PTO Type | 1000
|
| References |
 |
| The John Deere 20 Series New Generation Tractors by Benjamin Hain |
| JD500 Wheel Tractor published in 1965, by John Deere |
| Full-Line Specification Catalog published in 1966, by John Deere |
| Operator's Manual 720 Loader (OM-U26339) published in 1964 |
| John Deere Backhoes Swing into any digging job published in 1965 |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on March 19, 2025 |
