Kubota L1-435


Kubota L1-435 tractor photo
1987 - 1991
L1 Series
Compact Utility tractor
Series map:
L1-385
L1-435
L1-455
28.3kw
32.1kw
33.6kw
Production
ManufacturerKubota
Compact Utility tractor
Variants
L1-435DFour-wheel drive
Kubota L1-435 Engine
Kubota 1.5L 4-cyl diesel
Fuel tank12.2 gal
46.2 L
Engine details ...
Kubota L1-435 Power
Engine43 hp
32.1 kW
PTO (claimed)41.4 hp
30.9 kW
Mechanical
Two- or four-wheel drive
Open operator station.
Photos
No photos of the Kubota L1-435 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear TypeJIS1
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM545@2700
 942@2700
 913@2700
 1242@2700
Dimensions & Tires
Wheelbase72.8 inches
184 cm
Weight3153 to 3340 pounds
Front tire6.00-16
2WD Rear tire13.6-26
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
L1-435 references literature
Operator Manual L1 (30810-1921-4)
