Shibaura SD1300


Shibaura SD1300 tractor photo
1974 - ????
Compact Utility tractor
Production
ManufacturerShibaura
Compact Utility tractor
Variants
SD1300-0four-wheel drive
Shibaura SD1300 Engine
Shibaura 0.7L 2-cyl diesel
Fuel tank3.4 gal
12.9 L
Engine details ...
Shibaura SD1300 Power
Engine13.8 hp
10.3 kW
Mechanical
Two- or four-wheel drive
Manual steering
Open operator station.
Photos
No photos of the Shibaura SD1300 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Power Take-off (PTO)
Rear PTO Type540 (1.375)
Engine RPM540@2250
 856@2500
 1196@2500
Dimensions & Tires
Wheelbase49.6 inches
125 cm
Weight1213 lbs
550 kg
Front tire4.50-10
2WD Rear tire8-16
Full dimensions and tires ...
References
SD1300 references literature
SD1400 published in 1974, by Shibaura
