Kubota M7-174
| | 2023 - |
| M7-4 Series | | Row-Crop tractor |
|
Series map:
M7-154
M7-174
133.3hp*
155.6hp*
*Estimated engine power for comparison only.
| Production |
| Manufacturer | Kubota
|
| Row-Crop tractor |
| Kubota M7-174 Power |
| Engine (max) | 168 hp
125.3 kW
|
| PTO (claimed) | 140 hp
104.4 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Hydraulic wet disc brakes |
| Cab standard with air-conditioning. Available mechanical or pneumatic cab suspension. |
| Photos |
| No photos of the Kubota M7-174 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | closed center load-sensing
|
| Rear valves | 4 or 5
|
| Pump flow | 29 gpm
109.8 lpm
|
| Tractor hitch |
| Rear Type | III/IIIN
|
| Control | electronic lower-link draft sensing
|
| Rear lift (at ends) | 20723 lbs
9399 kg
|
| Rear lift (at 24"/610mm) | 11797 lbs
5351 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540/1000
|
| Front PTO Type | 1000
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 200
|
| Battery CCA | 1400
|
| Battery volts | 12
|
| Battery AH | 174
|
| References |
 |
| M7-4 Series published in 2022, by Kubota |
