Yanmar AF-24
|
|
| Production | |
| Manufacturer | Yanmar |
| Compact Utility tractor | |
| Yanmar AF-24 Engine | |
| Yanmar 1.4L 3-cyl diesel | |
| Fuel tank | 10 gal 37.9 L |
 Engine details ... | |
| Yanmar AF-24 Transmissions | |
| 16-speed shuttle | |
| 16-speed four-speed power shift | |
 Transmission details ... |
| Yanmar AF-24 Power | |
| Engine | 23.7 hp 17.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Two-post ROPS. Cab optional. |
| Photos | |
| No photos of the Yanmar AF-24 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS1 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 551@2500 |
| 756@2500 | |
| 963@2500 | |
| 1293@2500 | |
| -694@2500 | |
| Dimensions & Tires | |
| Wheelbase | 60.6 inches 153 cm |
| Weight | 2601 lbs 1179 kg |
| Front tire | 7-14 |
| Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 35 |
| Battery volts | 12 |
| Battery AH | 70 |
| References | |
 | |
| Super-Forte Mark III (198071-90015) published in 1992 |
