Tractors > Bad Boy > 1022

Bad Boy 1022



Bad Boy 1022 tractor photo
2021 -
10 Series
Sub-Compact Utility tractor
TYM built
Series map:
1022
1025
21.5hp
24.6hp
Production
DistributorBad Boy
ManufacturerTYM
Sub-Compact Utility tractor
Bad Boy 1022 Engine
Yanmar 1.0L 3-cyl diesel
Engine details ...
Bad Boy 1022 Transmission
hydrostatic
Transmission details ...
Bad Boy 1022 Power
Engine (gross)21.5 hp
16.0 kW
PTO (claimed)15.4 hp
11.5 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the Bad Boy 1022 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel6.6 gal
25.0 L
Hydraulic system3.6 gal
13.6 L
Hydraulics
Typeopen center
Capacity3.6 gal
13.6 L
Pump flow4.2 gpm
15.9 lpm
Total flow6.3 gpm
23.8 lpm
Steering flow2.1 gpm
7.9 lpm
Tractor hitch
Rear TypeIN
Controlposition control
Rear lift (at 24"/610mm)499 lbs
226 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@3200
Mid PTOindependent OptOptional
Engine RPM2500@3200
Dimensions & Tires
Wheelbase53.1 inches
134 cm
Weight1433 lbs
650 kg
Front tire16x7.50-9
Rear tire24x12.00-12
Full dimensions and tires ...
Bad Boy 1022 attachments
front-end loader
backhoe
Attachment details ...
1022 Serial Numbers
Location:Serial number decal on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
Charging amps40
Battery CCA500
Battery volts12
References
1022 references literature
Tractor Series published in 2021, by Bad Boy
Tractor Series published in 2023, by Bad Boy
Mow with an Attitude published in 2024, by Bad Boy
1022 manuals literature
Operator's Manual Model BBH100 Backhoe published in 2022
Operator's Manual BBL100 Front End Loader published in 2022
Operator's Manual Model 1022H published in 2022
