SAME Explorer3 105


SAME Explorer3 105 tractor photo
2012 - 2014
Explorer3 Series
Utility tractor
Series map:
Explorer3 90
Explorer3 105
65.6kw
76.1kw
Production
ManufacturerSAME
Utility tractor
SAME Explorer3 105 Engine
SAME 4.0L 4-cyl diesel
Fuel tank42.3 gal
160.1 L
Engine details ...
SAME Explorer3 105 Transmissions
15-speed partially synchronized
40-speed two-speed power shift
Transmission details ...
SAME Explorer3 105 Power
Engine (gross)102 hp
76.1 kW
Mechanical
Four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab with available air-conditioning.
Photos
No photos of the SAME Explorer3 105 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow14.8 gpm
56.0 lpm
Tractor hitch
Rear lift11684 lbs
5299 kg
 13669 lbsOptOptional
6200 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase94.5 inches
240 cm
4WD Wheelbase93.7 inches
237 cm
Weight8018 to 10185 pounds
Front tire380/85R24
Rear tire480/85R34
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
Explorer3 105 references literature
Explorer3 90-105 published in 2012, by SAME
