SAME Explorer3 85


SAME Explorer3 85 tractor photo
2004 - 2012
Model year
Explorer3 Series
Utility tractor
Series map:
Explorer3 85
Explorer3 100
63.4kw
73.8kw
Production
ManufacturerSAME
Utility tractor
SAME Explorer3 85 Engine
Deutz 4.0L 4-cyl diesel
Fuel tank42.3 gal
160.1 L
Engine details ...
SAME Explorer3 85 Transmissions
15-speed partially synchronized
40-speed two-speed power shift
Transmission details ...
SAME Explorer3 85 Power
Engine (gross)85 hp
63.4 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic front and rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Two-post ROPS. Available cab with air-conditioning.
Photos
No photos of the SAME Explorer3 85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pump flow14.8 gpm
56.0 lpm
Tractor hitch
Rear lift9480 lbs
4300 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Dimensions & Tires
2WD Wheelbase90.2 inches
229 cm
4WD Wheelbase90.9 inches
230 cm
Weight7055 to 9157 pounds
Front tire12.4R24
4WD Rear tire16.9R34
Full dimensions and tires ...
Electrical
Groundnegative
Battery volts12
References
Explorer3 85 references literature
Explorer3 85-100-110 published in 2011, by SAME
