SAME Explorer3 100
|
|
| Production | |
| Manufacturer | SAME |
| Utility tractor | |
| SAME Explorer3 100 Engine | |
| Deutz 4.0L 4-cyl diesel | |
| Fuel tank | 42.3 gal 160.1 L |
 Engine details ... | |
| SAME Explorer3 100 Transmissions | |
| 20-speed partially synchronized | |
| 40-speed two-speed power shift | |
 Transmission details ... |
| SAME Explorer3 100 Power | |
| Engine (gross) | 96 hp 71.6 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Hydraulic wet disc brakes | |
| Trailer brakes | hydraulic OptOptional |
| pneumatic OptOptional | |
| Two-post ROPS. Available cab with air-conditioning. | |
| Photos | |
| No photos of the SAME Explorer3 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Pump flow | 14.3 gpm 54.1 lpm |
| Tractor hitch | |
| Rear lift | 10582 lbs 4799 kg |
| 13669 lbsOptOptional 6200 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 |
| Front PTO | independent OptOptional |
| Clutch | electro-hydraulic wet disc |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| 2WD Wheelbase | 88.4 inches 224 cm |
| 4WD Wheelbase | 92.1 inches 233 cm |
| Weight | 7165 to 8378 pounds |
| Front tire | 14.9R24 |
| 4WD Rear tire | 16.9R34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Explorer3 85-100 published in 2006, by SAME |
